Radiant Tracer RTX-1200
Hazardous Location Ratings
78797f Class 1 Division I and II Group D Hazardous Location
CSA T - Code - T2C Ambient 40° This System Equipped for High Altitude.
For indoor / Outdoor Use.
Description
RTX-1200 Series model is designed to heat trace production, fuel gas, flare, venting, water lines and many other applications to a distance of 300' to 500' ft of tracing. Pump is designed to exhaust gas supply up to 40 PSI which can be utliized as another source of fuel gas supply or flare systems as pruge gas with proper installation.
System Components
Radiant Tracer Model RTX-1200 Series Heat Tracing System
Heat Tracer System , High Temperature Shut Down Controller , Temperature Gauges , All Connection Fittings
* Circulating Pump Sold Separately
Manufactured with CSA approved components.
|
Catalytic Adaptation Sizes |
12x24 - Catalytic Heater |
|
Heat Tracer Distance |
300 - 500 ft |
|
Temperature Control Range |
(50-104°F) 10 - 40°C |
| High Temperature Shut Down Setting |
176 °F / 80 °C |
|
Recommended Fluid |
Norkool Antifreeze |
| System Fluid Capacity |
5.5 Gals |
| BTU Input |
10,000 BTU per/ hr |
|
Heat Tracing Requirement |
½" Stainless tubing |
